Description
Huber KISS 205B
(Please Note: There is a 2 weeks Shipping lead time)
  Heating circulator with a stainless steel bath can be used for internal and external thermoregulation tasks. The temperature of various objects can be controlled by placing them directly within the bath. Externally connected applications can also be controlled with the addition of a pump adaptor.
Â
- KISS temperature controller
- Bright, large OLED display
- Simple operation with menu navigation
- Simultaneous display of setpoint, Tmin, Tmax and actual temperature
- Status displays for pump, cooling and heating
- Overtemperature and low level protection
- Safety class III/FL (DIN 12876)
- USB and RS232 interfaces
- Autostart function for power failure
- 3 colour versions available: grey (standard), blue, red
Â
Â
Â
Â
| General Information & Temperature Controller | |
|---|---|
| Temperature range | (-30) 45...200 °C |
| Temperature stability | ±0.05 °C |
| Temperature Display | OLED Display |
| Alarm message | optical, acoustical |
| Controller | KISS |
| Safety class | III / FL |
| Protection class | IP20 |
| Dimensions (W x D x H) | 178 x 337 x 355 mm | 7.01 x 13.27 x 13.98 inches |
| Weight | 9 kg | 19.84 pounds |
| Heating / Cooling Capacity | |
| Heating capacity | 1-1,5 kW |
| Circulation Pump | |
| Pressure pump max. | 14 lpm ; 0.25 bar | 3.7 gpm ; 362.5 psi |
| Suction pump max. | 10.5 lpm ; 0.17 bar | 27.74 gpm ; 246.5 psi |
| Pump connection | M16x1 AG male |
| Connections | |
| Digital interface | USB, RS232 |
| Operating Data | |
| old sku | 2040.0011.98 |
| Permissible ambient temp. | 5 to 40 °C |
| Bath opening W x D / BD | 105 x 90 / 150 mm | 4.13 x 3.54 / 5.91 inches |
| Bath volume | 5 Liters | 1.32 gal |
| Power supply | 100-115V 1~ 50/60Hz |
| Current max. | 15 A |
| Fusing | 15 A |
