The new Ai EasyChill series -30C 18 Cu Ft upright freezers is great for large storage of sample and products. Our unique compressor design with HC refrigerant offers you speedy cooling, great temperature uniformity inside the chamber, energy efficiency, and very quite operation.
The E18 is UL certified and is great for storage of Covid-19 vaccines, DNA, RNA, virus samples, organs and serum.
Important!
- Do not plug in your unit. Leave your Ai refrigerator or freezer for 24 hours before turning the unit on for the first time.
- This unit is NOT designed to be used on a mobile platform.
Specifications
Specifications
Model |
E18 |
Electrical requirements
|
115V (±10%) 60Hz 1-Phase, 600W, 6.5A
|
Performance |
Temperature range: -10°C to -30°C Time from ambient to -30°C: 3 hours Temperature uniformity: ±4°C Time from -30°C to -10°C with door closed (ambient 25°C): 5 hours
|
Controller |
Microprocessor-controlled, LED display |
Compressor |
Power: 110V 60Hz 1-PHASE Cooling type: direct cooling Defrost mode: manual Refrigerant: CFC-free, HC refrigerant
|
Chamber |
Dimensions: 27 x 24 x 48.3" (WxDxH) Material: coated steel Volume: 17.9 Cu Ft Number of chambers: two
|
Door and gasket
|
Two lockable door, with dual sealing gaskets
|
Working environment |
- Temperature: 10°C to 32°C (ideal temperature: 18°C to 25°C) - Humidity: <85% Rh - Altitude: < 2000 m / 6561 Ft - Stable, well-ventilated platform with no excessive dust - Keep freezer at least 12 inches from any walls or ceiling - Use dedicated power, do not share outlet - Extension power cable should be less than 10 feet is required - Freezer and power outlet should be grounded properly - Avoid direct sunlight, water spill and do NOT use freezer outdoor - Clean condenser fins and remove frost inside chamber at least once a month - Important! Do not plug in your unit. Leave your Ai refrigerator or freezer for 24 hours before turning the unit on for the first time.
|
Storage bin
|
Ten, plastic |
Battery backup system |
48 hours (for controller display and alarms only) |
Access port |
One, on the left of the freezer
|
Noise level
|
43 dBA |
Unit/shipping weight & dimensions
|
360 Lbs / 440 Lbs 36 x 32 x 73" / 38 x 25.5 x 80.5" (WxDxH)
|
Safety |
Compressor over-temp protection Compressor power surge delay protection External door with lock Sensor error, low battery, chamber high/low temperature, and remote alarms
|
Compliance |
UL 61010-1 CSA C22.2
|
Warranty |
One year |
|
Standard Packages
Standard Package
Part description
|
Quantity
|
Part image |
Ai E18 -30°C upright freezer
|
1 pc
|
|
Plastic storage bin
|
10 pcs |
|
Ice scraper |
1 pc |
|
Users manual |
1 pc
|
|
|
