Agilent IDP-7 5.4 cfm Oil-Free Compact Dry Scroll Pump

The new Agilent IDP-7 dry scroll pump is a compact, high performance, oil-free vacuum pump, delivering large pumping speed capacity and simple maintenance.

Agilent IDP dry scroll pumps are oil-free, compact, quiet, high performance vacuum pumps. IDP pumps use a single-sided scroll design that allows for a straightforward 15 minute maintenance procedure with simple tools. Large pumping speeds and compact sizes are ideal for many applications in the research, analytical instrument, and laboratory markets.

IDP pumps are hermetic, with the motor and all bearings completely isolated from the vacuum path. This design extends the bearing life and provides clean, dry vacuum to the application. An inlet isolation valve is available as an integral option that adds no additional height to the pump.

Agilent IDP7 Scroll Pump Features

• Includes the power cord & exhaust hose at no extra charge

• Digital hour meter for tracking service intervals

• Hermetically sealed for longer life

• Gas ballast allows for vacuum flexibility and higher vapor tolerance

• Do-It yourself maintenance

• Conforms with CE, CSA, CSA/CUS, Semi S2-703, and RoH

 Agilent’s 5.4 CFM dry scroll pump is oil-free – making it a clean, quiet, high performance vacuum pump. The IDP7 uses a single-sided scroll design that allows for a straightforward maintenance procedure with simple tools.

Oil-Free Is The Proper Pump Choice for Clean Rooms, Bio-Pharma, Nutraceutical Processes

With an oil-free scroll pump, there is no chance of having a product batch contaminated by “backstreaming” of the dirty hydrocarbon oils associated with oil-filled rotary vane vacuum pumps. Because it’s oil-free, the Agilent IDP7 does not smoke out of the exhaust or require filters and traps on the vacuum pump inlet and outlet.

Hermetically Sealed = Clean & Safe

Agilent’s IDP7 pump is hermetic, with the motor and all bearings completely isolated from the vacuum path. This design extends the bearing life and provides clean, dry vacuum to the application. The hermetic design of this pump allow for longer life by protecting the interior workings of the pump from aggressive solvents, corrosives, etc.

Pull Deeper Vacuum / Gas Ballast Positions 1 and 2

The IDP7 has two gas ballast ports that assist the pump in handling condensable gases such as water vapor, or other gaseous products that become liquids or solvents when reaching atmospheric pressure.

With neither of the gas ballast ports open, the IDP7 has a base pressure of 20 mTorr.

The port in position 1 provides for ~ 12 grams per hour of water vapor pumping, and limits the base pressure of the pump to not less than 200 mTorr.

The port in position 2 provides for ~ 120 grams per hour of water vapor pumping and limits the base pressure of the pump to not less than 1 Torr.
