Model KBF-S ECO 1020 | Humidity test chambers with environmentally friendly thermoelectric cooling

Only UL certified with 120v model


Thanks to thermoelectric cooling technology with patented heat dissipation, the new KBF-S ECO climatic chamber is one of the most energy-efficient constant climate chambers on the market. The thermoelectric cooling technology means the KBF-S ECO series is also very quiet during operation.



BENEFITS
• Safe thanks to standard-compliant testing according to the ICH Q1A guideline, even with a full load.
• Reliable thanks to failsafe operation without compromise.
• Smart, as a wide range of accessories makes it highly compatible for adaptation to specific customer requirements.
• Economical, as energy consumption is minimal thanks to optimized thermoelectric cooling.



Main Features

• Temperature range: 0 °C to +70 °C (max. 24 °C under ambient temperature
• Humidity range: 10% to 80% RH
• APT.line™ preheating chamber technology
• LCD to display temperature and humidity along with additional information and alarms
• Internal data logger, measured values can be read out in open format via USB
• Unit self-test for comprehensive status analysis
• Inner chamber made completely of stainless steel
• 2 stainless steel racks, including shelf carrier
• Access port with silicone plug Ø 30 mm, left
• Computer interface: Ethernet



















Videos

Specifications
Technical Specifications

Designation

KBFSECO1020-230V

KBFSECO1020UL-120V
Option model

Standard

Standard
Temperature range (max. 24 °C under ambient temperature) 0...70 °C (max. 24 °C under ambient temperature) 0...70 °C
Max. heat compensation at 40°C 400 W 400 W
Temperature range with humidity (max. 24 °C under ambient temperature) 5...70 °C (max. 24 °C under ambient temperature) 5...70 °C
Humidity range 10...80 % r.F. 10...80 % r.F.
Temperature uniformity at 25°C and 60% RH 0.1 ± K 0.1 ± K
Temperature uniformity at 40°C and 75% RH 0.5 ± K 0.5 ± K
Temperature fluctuation at 25°C and 60% RH 0.1 ± K 0.1 ± K
Temperature fluctuation at 40°C and 75% RH 0.1 ± K 0.1 ± K
Humidity fluctuation at 40°C and 75% RH 0,4 % r.F. 0,4 % r.F.
Recovery time after door was opened for 30 s at 25°C and 60% RH 5 min 5 min
Recovery time after door was opened for 30 s at 40°C and 75% RH 15 min 15 min
Interior volume 1020 L 1020L
Width 973 mm 973 mm
Height 1250 mm 1250 mm
Depth 836 mm 836 mm
Permitted load 150 kg 150 kg
Load per rack 45 kg 45 kg
Unit doors  2 2
Wall clearance back 100 mm 100 mm
Wall clearance sidewise 180 mm 180 mm
Width net 1254 mm 1254 mm
Height net  1925 mm 1925 mm
Depth net 1146 mm 1146 mm
Net weight of the unit 322kg 322kg
Rated Voltage 200...230 V 100...120 V
Power frequency 50/60 Hz 50/60 Hz
Unit fuse 16 A 16 A
Phase (Nominal voltage) 1~ 1~
Nominal power 1,2 kW 1,2 kW
Energy consumption at 40°C and 75% RH 135 Wh/h 135 Wh/h
Sound-pressure level 49 dB(A) 49 dB(A)
Number of shelves (std./max.) 2/15 2/15
